Outback MATE - Page 112

112
CHARGER
MAIN----------------
6:54:42P
SUM STATUS SETUP ADV
ADV/SETTINGS/WARNING
changes made could
adversely eect
system performance
ADV/PASSWORD--------
enter the password:
132
ENTER INC DEC EXIT
ADV/FX/CHARGER---P00
charger 12.0 aac
limit
DOWN INC DEC PORT
ADV/FX/CHARGER------
absorb 28.8 vdc
setpoint
DOWN INC DEC PORT
ADV/FX/PAGE1--------
choose category:
ADV INV CHGR PG2
ADV-----------------
choose device:
FX CC MATE MAIN
ADV/FX/CHARGER---P00
absorb 02.0 hrs
time limit
DOWN INC DEC PORT
ADV/FX/CHARGER---P00
oat 26.8 vdc
setpoint
DOWN INC DEC PORT
ADV/FX/CHARGER----P00
oat 00.5 hrs
time period
DOWN INC DEC PORT
ADV/FX/CHARGER----P00
reoat 25.0 vdc
setpoint
DOWN INC DEC PORT
ADV/FX/CHARGER----P00
equalize 28.8 vdc
setpoint
DOWN INC DEC PORT
ADV/FX/CHARGER----P00
equalize 02.0 hrs
time period
DOWN INC DEC PORT
ADV/FX/CHARGER------
charger programming
completed
TOP ADV MAIN
GRID
MAIN----------------
6:54:42P
SUM STATUS SETUP ADV
ADV/SETTINGS/WARNING
changes made could
adversely eect
system performance
ADV/PASSWORD--------
enter the password:
132
ENTER INC DEC EXIT
ADV/FX/PAGE1--------
choose category:
ADV INV CHGR PG2
ADV-----------------
choose device:
FX CC DC MATE
ADV/FX/PAGE2--------
choose category:
ADV GRID GEN PG3
ADV/FX/GRID---------P00
ac1/grid 100 vac
lower limit
DOWN INC DEC PORT
ADV/FX/GRID----------P00
ac1/grid 60.0 aac
input limit
DOWN INC DEC PORT
ADV/FX/GRID----------P00
ac1/grid 3 cycles
transfer delay
DOWN INC DEC PORT
ADV/FX/GRID---------
GRID programming
completed
TOP ADV MAIN
ADV/FX/GRID----------P00
ac1/grid 140 vac
upper limit
DOWN INC DEC PORT
GENERATOR
MAIN----------------
6:54:42P
SUM STATUS SETUP ADV
ADV/SETTINGS/WARNING
changes made could
adversely eect
system performance
ADV/PASSWORD--------
enter the password:
132
ENTER INC DEC EXIT
ADV/FX/PAGE1--------
choose category:
ADV INV CHGR PG2
ADV/FX/PAGE2--------
choose category:
ADV GRID GEN PG3
ADV-----------------
choose device:
FX CC DC MATE
ADV/FX/GEN-----------P00
gen input 00.5 min
connect delay
DOWN INC DEC PORT
ADV/FX/GEN-----------P00
ac2/gen 100 vac
lower limit
DOWN INC DEC PORT
