Outback MATE User Manual

28
To debug the system, press the <DEBUG> so
key.
On the DEBUG screen, rst press the <VIEW>
so key to bring up a list of HUB ports with a
count of communications errors for each port;
<RESET> allows you to reset the error counting
display (see next screen).
is is a typical VIEW screen showing the HUB
Ports and any communication errors in the
system. e numbered port with more than one
error will need correcting. Aer the errors are
corrected, all the used ports will return to 000
or 001 values aer pushing the <RSET> so key.
Press any so key to return to the SETUP/MATE/
COMM screen. To correct errors, please see “Er-
rors and Debugging” in the section that follows. If
no errors are present, pressing any so key returns
to the previous SETUP/MATE/COMM screen.
Press the <RSET> so key to clear the error-
counting display. Press the <BACK> so key
to return to the “choose category” screen. Press
<VIEW> to return to the previous screen.
SETUP/MATE/COMM--------------
comm errors:
BACK VIEW RSET
00:000 01:000 02:000
03:000 04:025 05:001
06:001 07:001 08:001
09:001 10:001 2M:001
SETUP/MATE/COMM--------------
comm errors:
BACK VIEW RSET
SETUP/MATE/PAGE2--------------
choose category:
BACK REPOLL PC DEBUG

Outback MATE Specifications

General

Display	LCD
Operating Temperature Range	-20°C to 60°C
Mounting	Wall Mount
Type	System Display and Controller
Communication	RS232
Communication Ports	RS232
