HBX-Drop Grid Set Point
HBX-Drop Grid Delay
ADV/MATE/HBX---------------------
hbx-drop 26.0 vdc
grid set point
DOWN UP INC DEC
ADV/MATE/HBX---------------------
hbx-drop 01.0 hrs
grid delay
DOWN UP INC DEC
is set point shows the voltage—26.0 VDC
is the default for a 24V system—at which the
FX will DROP its AC input source. e battery
voltage must remain above this voltage for the
amount of time set by HBX-DROP GRID DELAY
(next screen) for a DROP to be issued. Press the
<DOWN> so key to proceed.
is set point is the amount of time—01.0 hrs in
this case—battery voltage must remain above the
HBX-DROP GRID SET POINT (see previous
screen) before a DROP command is sent. It can
range from 00.1 hrs to 24.0 hrs in 0.1 hour incre-
ments. ese increments are adjusted using the
<INC> and <DEC> so keys. Press the <DOWN>
so key to proceed.
With this screen, HBX Mode can be enabled or
disabled. Pressing <CHANGE> allows you to
change the current mode in the next screen.
AC Input Control
ADV/MATE/HBX---------------------
ac input USE
control
DOWN UP CHANGE
NOTE: Before enabling HBX Mode, make sure the
FX is in DROP mode by pressing the <DROP>
so key. e screen will indicate DROP mode,
allowing the MATE to reset the HBX values.
ADV/MATE/HBX---------------------
ac input USE
control
DROP USE HBX DONE
