Outback MATE User Manual

64
Disable HBX
ADV/MATE/HBX----------------------
ac input DROP
control
DROP USE HBX DONE
ADV/MATE/HBX----------------------
ac input DROP-HBX
control
DROP USE HBX DONE
Enable HBX by pressing the <HBX> so key. e
screen now indicates the MATE is running in
HBX mode by displaying the current state, USE or
DROP followed by HBX.
ADV/MATE/HBX-------------
ac input DROP-HBX
control
DROP USE HBX DONE
ADV/MATE/HBX----------------------
ac input DROP
control
DROP USE HBX DONE
ADV/MATE/HBX---------------------
ac input DROP
control
DOWN UP CHANGE
To disable HBX Mode, press the <HBX> so key
again. Aer disabling HBX, the system remains in
whichever state—DROP or USE—it was in while
HBX Mode was active. Be sure to reset the DROP
or USE to the desired state once it’s out of HBX
Mode.
Pressing the <DONE> so key returns to the last
HBX activated USE menu.
Press either the <UP> or <DOWN> so keys to
return to the ADVANCED menu.

Outback MATE Specifications

General

Display	LCD
Operating Temperature Range	-20°C to 60°C
Mounting	Wall Mount
Type	System Display and Controller
Communication	RS232
Communication Ports	RS232
