5.Menu Interpretation
41
Set the time axis, depth axis and AF trigger of AM modulation.
1) [Time Axis►]
Set the time axis parameters.
⚫ [Ref.Value]
Set the starting reference time on the time axis.
⚫[Position]
Set the reference position of the waveform on the time axis.
⚫ [Scale/Div Auto Man]
Automatically or manually set the grid division scale.
⚫ [Return]
Return to the previous menu.
2)[Depth Axis►]
Set the depth axis parameters.
⚫ [Ref Depth]
Set the reference offset position as a vertical percentage.
⚫[Position]
Set the reference position of the waveform on the depth axis.
⚫[Scale/Div Auto Man]
Automatically or manually set the grid division scale.
⚫[Return]
Return to the previous menu.
3)[AF Trigger►]
Set the AF triggering conditions.
⚫[AF Trigger On Off]
Set the AF trigger to be On or Off.
⚫[Edge Pos Neg]
Set the trigger to rising or falling edge.
⚫[Trigger Mode]
