Owon XSA800 Series User Manual

5.Menu Interpretation
42
Set the triggering mode to single trigger or continuously trigger.
⚫[Trigger Level]
Set the trigger level as a percentage of the depth.
⚫ [Trigger Delay]
Set the trigger delay time.
⚫[Return]
Return to the previous menu.
5.12.2.2 [FM►]
Enter FM demodulation soft menu.
5.12.2.2.1 [FM On Off]
Turn FM demodulation On or Off.
5.12.2.2.2 [Carrier Freq]
Set the carrier frequency of the FM modulation signal.
5.12.2.2.3 [IF BW]
Set the demodulation bandwidth.
5.12.2.2.4 [Data Reset]
Set the maximum, minimum, and average data reset under the FM
modulated signal.
5.12.2.2.5[Setup►]
Set the time axis, deviation axis and AF trigger of FM modulation.
1) [Time Axis►]
Set the time axis parameters.
⚫[Ref.Value]
Set the starting reference time on the time axis.
⚫[Position]
Set the reference position of the waveform on the time axis.
⚫ [Scale/Div Auto Man]
