Pace PAI - FIGURE 61 - Polyurethane Caulk (Grey: P;N 021-19568-000; Champagne: P;N 013-03317-040) for Pipe Chase; FIGURE 62 - Roof Seam Cap (Assembled); FIGURE 63 - Pipe Chase, Trim Angle, and Cover; FIGURE 64 - Hood

108 pages

Save Page as PDF

To Next Page

To Previous Page

Form PA102.20-N1

Installation & Assembly Manual │ PACESECTION 3 - HANDLING, STORAGE, AND INSTALLATION

Issue Date: 07/03/2018

LD116505

Figure 61 - Polyurethane caulk (Grey: P/N 021-

19568-000; Champagne: P/N 013-03317-040) For

Pipe Chase Only

Never use silicone caulk/sealant in or

on any air handling equipment.

LD17322

Figure 62 - Roof Seam Cap (Assembled)

Apply 2 in. Gasket

and Caulk

Apply Caulk

Pipe Chase Base Rail Cover

Pipe Chase

Trim Angle

Apply 2 in.

Gasket

and Caulk

LD16502

Figure 63 - Pipe Chase, Trim Angle, and Cover

Figure 64 - Hood

LD116503
