SECTION 3 - HANDLING, STORAGE, AND INSTALLATIONPACE │ Installation & Assembly Manual

Issue Date: 07/03/2018

Form PA102.20-N1

Additional Parts

The following parts may be used later in these instruc-

tions.

Figure 65 - Damper Shaft Extension Kit (P/N 026-

33715-002)

LD116504

LD16514

Figure 66 - Corner Connector Hole Plug (P/N 021-

19568-000) (8)

Figure 67 - Touch-Up Spray - 12 Oz.

(P/N 013-03322-000)

LD116506

Figure 68 - Shipping Split Corner Gasket - 3.5 X 3. 5

(P/N 028-11883-010)

LD116507

Figure 69 - Spare Fan Belt

LD116511

Figure 70 - Conduit (P/N 025-39024-001) and SJO

Cord (P/N 025-35746-001)
