Table 2 - Koch Filter Clips - Single Filter Application
2 IN MICROMAX 4 IN MICROMAX
MULTI-CELL FM SINGLE
HEADER (SH) OR MULTI-SAK
MULTI-CELL SBM
DOUBLE HEADER (DH)
P/N 026-35778-702 X X
P/N 026-35778-604 X
P/N 026-35778-612 X
Table 3 - Koch Filter Clips - Pre-Filter / Final Filter Application
2 IN MULTI-PLEAT
ELITE OR CLEANABLE
OR THROWAWAY AND
MULI-CELL FM SINGLE
HEADER (SH) OR
MULTI-SAK
2 IN MULTI-PLEAT
ELITE OR CLEANABLE
OR THROWAWAY AND
MULTI-CELL SBM
DOUBE HEADER
4 IN MULTI-PLEAT
XL8 AND MULTI-CELL
FM SINGLE HEADER
(SH) OR MULTI-SAK
4 IN MULTI-
PLEAT ELITE
AND MULTI-CELL
SBM DOUBLE
HEADER
P/N 026-35778-702
and 026-35778-604
X
P/N 026-35778-612
and 026-35778-625
X
P/N 026-35778-702
and 026-35778-605
X
P/N 026-35778-612
and 026-35778-626
X
Note: When lters are supplied by other companies, the lter clips are supplied as well.
Table 4 - AAF Clips for Filter Frames - Single Filter Application
2 IN PERFECTPLEAT,
PREMIUM OR
PREMIUM HM
4 IN AMAIR 300X
VARICEL SINGLE
HEADER (SH) OR
DRIPAK 2000
VARICEL DOUBLE
HEADER (DH)
FILTER FRAME
12X24 - 16 G
GALVANIZED
P/N 026-35778-000 X X
P/N 026-35778-007 X
P/N 026-35778-006 X
FILTER FRAME
24X24 - 16 G
GALVANIZED
P/N 026-35778-000 X X
P/N 026-35778-007 X
P/N 026-35778-006 X
