17
2. Extract the microphone module.
Fig. 27 Removing the microphone module.
LCD Panel
To remove the LCD panel, first remove the microphone (see Microphone on page 16) and then
perform the following steps:
1. Remove the five screws securing the LCD module.
Fig. 28 Location of the LCD panel screws.
Packard Bell dot Disassembly Manual
