21
2. Take out the wireless LAN adapter from the socket.
Fig. 35 Removing the wireless LAN adapter.
Main Board
To remove the main board, remove the USB/LED/power/card reader board (see
USB/LED/Power/Card Reader Board
on page 9), remove the wireless LAN adapter (see Wireless
LAN Adapter on page 20), and then perform the following steps:
1. Disconnect the speaker cable from the header on the main board.
Fig. 36 Location of the speaker cable header on the main board.
Packard Bell dot Disassembly Manual
