Packard Bell dot - Removing Main Board Screw; Speaker Assembly Removal

22
2. Remove the screw securing the main board.
Fig. 37 Location of the main board screw.
3. Lift out the main board.
Fig. 38 Removing the main board.
Speaker Assembly
To remove the speaker assembly, first remove the top cover (see Top and Base Cover on page 6),
and then perform the following steps:
Packard Bell dot Disassembly Manual
