Establishing electrical connections
Wireless remote
control
The receiver for a wireless remote control is prewired and only has
to be clipped onto to slot J31 and J2 on the circuit board and con-
nected to ground. You will then have to attach the receiver to the
stand tube. The receiver and the wireless remote control are pread-
justed so that they are immediately operational. A detailed descrip-
tion is supplied with the wireless remote control.
NOTE
If the manual cable switch is on the attachment, this is not supplied with a socket but
is connected via a junction box with the wire from the circuit board. The manual
cable switch is then fixed and cannot be unplugged. The required circuit diagram is
available on request from PALFINGER Tail Lifts.
