51
Adjusting and testing installed tail lift
10.2 Air bleeding the hydraulic cylinders
Raise and lower the platform several times.
Open and close the platform several times.
10.3 Checking horizontal position on ground
Open and lower the platform until it sets down on the ground.
Check that the platform rests horizontally on the ground.
If the platform does not lie level, release the screw on tilt switch
b16.
Adjust tilt switch b16 so that the platform rests level on the
ground.
Retighten the screw on tilt switch b16.
Observe the torque of 9 Nm.
NOTE
This test only has to be performed if tilt switch b16 is provided.
