8.3. COMPRESSOR OPERATING FREQUENCY OPERATION
Compressor Operation Frequency According to Comp. Operation Frequency Command Number(INDOOR UNIT)
8.3.1. Cooling & Soft Dry
(Unit : Hz)
Comp.Operation Frequency Command Number of Indoor Unit A
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
Comp.
Operation
Frequency
Command
Number of
Indoor Unit B
0 0 15 15 15 15 15 22 30 39 45 47 65 67 67 67 67
1 30 30 39 43 45 47 50 52 56 57 61 61 61 61 61
2 30 30 39 43 45 47 50 52 56 57 61 61 61 61 61
3 39 39 41 45 47 48 52 54 57 59 63 63 63 63 63
4 15
15
15
15
43 43 45 48 50 52 56 57 61 63 67 67 67 67 67
5 15 45 45 47 50 52 54 57 59 63 65 68 68 68 68 68
6 22 47 47 48 52 54 56 59 61 65 67 70 70 70 70 70
7 30 50 50 52 56 57 59 63 65 68 70 74 74 74 74 74
8 39 52 52 54 57 59 61 65 67 70 72 75 75 75 75 75
9 45 56 56 57 61 63 65 68 70 74 75 75 75 75 75 75
10 47 57 57 59 63 65 67 70 72 75 75 76 76 76 76 76
11 65 61 61 63 67 68 70 74 75 75 76 77 77 77 77 77
12 67 61 61 63 67 68 70 74 75 75 76 77 77 77 77 77
13 67 61 61 63 67 68 70 74 75 75 76 77 77 77 77 77
14 67 61 61 63 67 68 70 74 75 75 76 77 77 77 77 77
15 67 61 61 63 67 68 70 74 75 75 76 77 77 77 77 77
Rated and Maximum Operation frequency
Compressor Operation Frequency (Hz)
One Indoor Unit Operation Two Indoor Units Operation
Fc (10) 47 75
Fc max (15) 67 77
8.3.2. Heating
(Unit : Hz)
Comp.Operation Frequency Command Number of Indoor Unit A
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
Comp.
Operation
Frequency
Command
Number of
Indoor Unit B
0 0 15 25 35 45 55 55 65 69 74 75 93 106 118 118 118
1 15 45 55 65 69 71 72 74 75 77 77 78 81 83 83 83
2 25 55 65 69 71 72 74 75 77 78 78 80 83 84 84 84
3 35 65 69 71 72 74 75 77 78 80 80 81 84 86 86 86
4 45 69 71 72 74 75 77 78 80 81 81 83 86 87 87 87
5 55 71 72 74 75 77 78 80 81 83 83 84 87 89 89 89
6 55 72 74 75 77 78 80 81 83 84 84 86 89 90 90 90
7 65 74 75 77 78 80 81 83 84 86 86 87 90 92 92 92
8 69 75 77 78 80 81 83 84 86 87 87 89 92 93 93 93
9 74 77 78 80 81 83 84 86 87 89 89 90 93 94 94 94
10 75 77 78 80 81 83 84 86 87 89 90 92 93 100 100 100
11 93 78 80 81 83 84 86 87 89 90 92 93 94 106 106 106
12 106 81 83 84 86 87 89 90 92 93 93 94 106 112 112 112
13 118 83 84 86 87 89 90 92 93 94 100 106 112 125 125 125
14 118 83 84 86 87 89 90 92 93 94 100 106 112 125 125 125
15 118 83 84 86 87 89 90 92 93 94 100 106 112 125 125 125
Rated and Maximum Operation frequency
Compressor Operation Frequency (Hz)
One Indoor Unit Operation Two Indoor Units Operation
Fh (10) 75 90
Fh max (15) 118 125
