17 Electronic Parts List
( Model:CWA742020 ) INDOOR PCB
SYMBOL PART NO. DESCRIPTION & NAME REMA
RKS
BZ1 A48040 BUZZER M
D1,D2,D4,D5,D7,D8 A541SS355T DIODE M
D3,D6,D9 A54DIF60 DIODE M
DB1 A54D3SBA60F1 DIODE BRIDGE M
FUSE XBA2C31TR0 FUSE M
IC1 A5278366F105 INTERGRATED CIRCUIT M
IC2 A52BR9020F INTERGRATED CIRCUIT M
IC3 A52MPC393G22 INTERGRATED CIRCUIT M
IC4 A52PST600DR INTERGRATED CIRCUIT M
IC5,IC6 A52A2003GR2 INTERGRATED CIRCUIT M
IC7,IC8 A52C108 INTERGRATED CIRCUIT M
ICX A53805A INTERGRATED CIRCUIT M
PC1 A52S2501L1KC PHOTO COUPLER M
PC2 A52TLP371LF PHOTO COUPLER M
PC3 A52LP521L1BL PHOTO COUPLER M
Q1,Q3,Q4,Q7,Q8,Q10 A55DA143XKTX TRANSISTOR M
SW3,SW4 A01059 SWITCH M
T1 A40C1002 TRANSFORMER M
X1 A45CTS4MG02T RESONATOR M
ZNR1 ERZVEAV511 ZNR M
ZNR2 ERZVA9V271 ZNR M
( Model:CWA73C1093 ) OUTDOOR PCB
SYMBOL PART NO. DESCRIPTION & NAME REMA
RKS
C-FM A31735 CAPACITOR-FM M
D1,D2,D3,D4,D5,D6 A541SS355T DIODE M
D25,D26,D27,D28,D29,D30 A541SS355T DIODE M
D200,D201 A54DIF60 DIODE M
D202 A54RA15-10V3 DIODE M
D203,D204,D205 A54DIF60 DIODE M
D210 A54EC11FS2TL DIODE M
D211 A54SC201-4T DIODE M
D212 A54EC11FS2TL DIODE M
D214,D215,D216,D217 A54SC201-4T DIODE M
ZD201,ZD202 A54D5.6EB3TB ZENAR DIODE M
PC1,PC2 A52LP521LIGB PHOTO COUPLER M
PC3 A52TLP2531LF PHOTO COUPLER M
PC12 A52LP620LIGB PHOTO COUPLER M
PC13 A52LP521LIGB PHOTO COUPLER M
PC200,PC201 A52PS2633EL PHOTO COUPLER M
PC202,PC203 A52LP521LIBL PHOTO COUPLER M
PC204 A52LP521LIGB PHOTO COUPLER M
FUSE102 XBA2C31TRO FUSE M
FUSE201 XBA2C50TRO FUSE M
IC3 A52MPC339G22 INTERGRATED CIRCUIT M
IC6 A52A2003GR2 INTERGRATED CIRCUIT M
IC7 A52MPC393G22 INTERGRATED CIRCUIT M
IC12 A52PST600DR INTERGRATED CIRCUIT M
IC201 A52S13050NAF INTERGRATED CIRCUIT M
IC202 A52S13150NAF INTERGRATED CIRCUIT M
IC204,IC205 A52A2003GR2 INTERGRATED CIRCUIT M
IC206 A52TC4052FEL INTERGRATED CIRCUIT M
IC207 A52MPC393G22 INTERGRATED CIRCUIT M
IC208 A52S13150NAF INTERGRATED CIRCUIT M
ICX1 A53806B SERIAL PROM M
ICX2 A53812B SERIAL PROM M
Q1,Q2 A55DA143XKTX TRANSISTOR M
Q4,Q5 A55A146ITI TRANSISTOR M
Q9 A55DA143XKTX TRANSISTOR M
Q10 A55DA143TKTX TRANSISTOR M
Q200,Q202 A55DA143XKTX TRANSISTOR M
LED1 A54SEC180IC LED M
LED200,LED201 A54SEC140IC LED M
LED202 A54SEC180IC LED M
LED203 A54SEC140IC LED M
VR1 A44EVMEASB22 VARISTOR M
VR200 A44EVMEASB13 VARISTOR M
RY-AC A00139 RELAY M
86
CS-MVG103KE / CU-MVG153KE
