Part Name Figure Qā€™ty Remarks
Washer
For suspending indoor unit
from ceiling
Flare insulator
For gas and liquid tubes
Hose band
For securing drain hose
Foam drain
socket
For drain hole
(another side of drain hose)
Drain hose
Flange
For inlet duct installation
Screw
8
2
5
1
1
2
4
Use M10 for suspension bolts.
Suspension bolts and nuts are field supply.
