Panasonic CZ-KPY3A series Service Manual

1
1-410
Outdoor air intake temp(°C D.B.)
Model
Power
Source
Ambient
Return
Air
25°C 30°C 35°C 40°C 46°C
DB WB TC SHC IPT TC SHC IPT TC SHC IPT TC SHC IPT TC SHC IPT
S-140PT2E5A
U-140PE1E5A
(U-140PE1E8A)
220V
230V
240V
50Hz
1phase
(3phase)
23
16 13.6 9.6 4.58 13.6 9.6 4.93 13.1 9.3 5.24 12.2 9.0 5.45 8.9 7.5 4.45
19 14.6 7.5 4.78 14.6 7.5 5.14 14.0 7.2 5.47 13.0 6.9 5.68 9.5 5.4 4.65
22 16.0 5.5 4.95 16.0 5.4 5.32 15.4 5.3 5.65 14.3 4.8 5.88 10.4 3.5 4.81
25
16 14.1 11.3 4.66 14.1 11.3 5.01 13.6 11.0 5.33 12.6 10.7 5.54 9.2 9.1 4.53
19 15.1 9.2 4.86 15.1 9.1 5.22 14.5 8.8 5.56 13.5 8.5 5.78 9.9 7.0 4.72
22 16.5 6.9 5.03 16.5 7.0 5.40 15.9 6.7 5.75 14.8 6.4 5.98 10.8 4.9 4.89
27
16 14.6 13.0 4.74 14.6 13.1 5.09 14.0 12.7 5.42 13.1 12.5 5.63 9.5 9.4 4.60
19 15.6 10.9 4.94 15.6 10.8 5.31 15.0 10.4 5.65 14.0 10.2 5.88 10.2 8.6 4.80
22 17.1 8.6 5.11 17.1 8.7 5.49 16.4 8.4 5.85 15.3 8.0 6.08 11.2 6.5 4.97
29
16 14.8 14.6 4.75 14.8 14.6 5.10 14.3 14.1 5.43 13.3 13.1 5.65 9.7 9.6 4.62
19 15.8 12.3 4.96 15.8 12.4 5.32 15.2 12.0 5.66 14.2 11.8 5.89 10.4 10.1 4.81
22 17.3 10.2 5.13 17.3 10.3 5.51 16.7 10.0 5.86 15.5 9.5 6.09 11.3 7.9 4.98
32
16 15.0 14.8 4.76 15.0 14.8 5.12 14.5 14.3 5.44 13.4 13.2 5.66 9.8 9.7 4.63
19 16.1 12.5 4.97 16.1 12.6 5.34 15.4 12.1 5.68 14.4 11.9 5.91 10.5 10.2 4.83
22 17.6 10.4 5.14 17.6 10.5 5.52 16.9 10.1 5.87 15.7 9.7 6.11 11.5 8.0 4.99
1-13. Capacity Table
1. Cooling Capacity Performance Data
•
Combination of Single Unit
Ceiling Type
TC :Cooling Capacity
SHC :Sensible Heat Capacity
IPT :Cooling Power Consumption
unit : kW
SM830231-02Single欧州.indb410SM830231-02Single欧州.indb410 2014/09/1913:22:102014/09/1913:22:10
