Panasonic CZ-KPY3A series Service Manual

1
1-411
Outdoor air intake temp(°C D.B.)
Model
Power
Source
Ambient
Return
Air
25°C 30°C 35°C 40°C 46°C
DB WB TC SHC IPT TC SHC IPT TC SHC IPT TC SHC IPT TC SHC IPT
S-36PT2E5A×2
U-71PE1E5A
(U-71PE1E8A)
220V
230V
240V
50Hz
1phase
(3 phase)
23
16 8.1 6.7 2.36 7.9 6.7 2.53 7.6 6.5 2.72 7.2 6.4 2.70 6.3 6.0 2.31
19 8.5 4.9 2.45 8.3 5.0 2.61 8.0 4.8 2.78 7.5 4.5 2.72 6.6 4.2 2.34
22 9.0 3.2 2.55 8.7 3.1 2.71 8.3 3.0 2.86 7.8 2.8 2.75 6.8 2.4 2.36
25
16 8.1 7.8 2.36 7.9 7.7 2.53 7.6 7.6 2.72 7.2 7.2 2.70 6.3 6.3 2.31
19 8.5 6.0 2.45 8.3 5.9 2.61 8.0 5.8 2.78 7.5 5.6 2.72 6.6 5.2 2.34
22 9.0 4.3 2.55 8.7 4.2 2.71 8.3 4.1 2.86 7.8 3.9 2.75 6.8 3.5 2.36
27
16 8.1 8.1 2.36 7.9 7.9 2.53 7.6 7.6 2.72 7.2 7.2 2.70 6.3 6.3 2.31
19 8.5 7.0 2.45 8.3 7.0 2.61 8.0 6.8 2.78 7.5 6.6 2.72 6.6 6.3 2.34
22 9.0 5.3 2.55 8.7 5.2 2.71 8.3 5.0 2.86 7.8 4.8 2.75 6.8 4.5 2.36
29
16 8.1 8.1 2.36 7.9 7.9 2.53 7.6 7.6 2.72 7.2 7.2 2.70 6.3 6.3 2.31
19 8.5 8.1 2.45 8.3 8.0 2.61 8.0 7.8 2.78 7.5 7.5 2.72 6.6 6.6 2.34
22 9.0 6.4 2.55 8.7 6.3 2.71 8.3 6.0 2.86 7.8 5.9 2.75 6.8 5.6 2.36
32
16 8.1 8.1 2.36 7.9 7.9 2.53 7.6 7.6 2.72 7.2 7.2 2.70 6.3 6.3 2.31
19 8.5 8.1 2.45 8.3 8.0 2.61 8.0 7.8 2.78 7.5 7.5 2.72 6.6 6.6 2.34
22 9.0 6.4 2.55 8.7 6.3 2.71 8.3 6.0 2.86 7.8 5.9 2.75 6.8 5.6 2.36
S-36PT2E5A×3
U-100PE1E5A
(U-100PE1E8A)
220V
230V
240V
50Hz
1phase
(3phase)
23
16 11.4 10.0 3.12 11.4 10.0 3.36 10.9 9.7 3.57 10.2 9.5 3.71 7.4 7.4 3.03
19 12.1 7.3 3.26 12.1 7.3 3.50 11.7 7.1 3.72 10.9 6.8 3.87 7.9 5.6 3.17
22 13.3 4.8 3.37 13.3 4.8 3.62 12.8 4.7 3.85 11.9 4.3 4.01 8.7 3.2 3.28
25
16 11.8 11.8 3.18 11.8 11.8 3.41 11.3 11.3 3.63 10.5 10.5 3.78 7.7 7.7 3.09
19 12.6 9.3 3.31 12.6 9.3 3.56 12.1 9.0 3.79 11.2 8.7 3.94 8.2 7.4 3.22
22 13.8 6.7 3.43 13.8 6.7 3.68 13.2 6.4 3.92 12.3 6.2 4.07 9.0 4.9 3.33
27
16 12.2 12.2 3.23 12.2 12.2 3.47 11.7 11.7 3.69 10.9 10.9 3.84 8.0 8.0 3.14
19 13.0 11.4 3.37 13.0 11.4 3.62 12.5 11.0 3.85 11.6 10.8 4.00 8.5 8.5 3.27
22 14.2 8.6 3.49 14.2 8.6 3.74 13.7 8.5 3.98 12.7 8.1 4.14 9.3 6.8 3.39
29
16 12.4 12.4 3.24 12.4 12.4 3.48 11.9 11.9 3.70 11.0 11.0 3.85 8.1 8.1 3.15
19 13.2 13.2 3.38 13.2 13.2 3.63 12.7 12.7 3.86 11.8 11.8 4.01 8.6 8.6 3.28
22 14.5 10.7 3.49 14.5 10.7 3.75 13.9 10.3 3.99 12.9 10.1 4.15 9.5 8.7 3.39
32
16 12.5 12.5 3.25 12.5 12.5 3.49 12.1 12.1 3.71 11.2 11.2 3.86 8.2 8.2 3.15
19 13.4 13.4 3.39 13.4 13.4 3.64 12.9 12.9 3.87 12.0 12.0 4.02 8.8 8.8 3.29
22 14.7 10.8 3.50 14.7 10.8 3.76 14.1 10.4 4.00 13.1 10.3 4.16 9.6 8.8 3.40
S-50PT2E5A×2
U-100PE1E5A
(U-100PE1E8A)
220V
230V
240V
50Hz
1phase
(3phase)
23
16 11.4 8.7 3.12 11.4 8.7 3.36 10.9 8.4 3.57 10.2 8.2 3.71 7.4 6.8 3.03
19 12.1 6.6 3.26 12.1 6.6 3.50 11.7 6.4 3.72 10.9 6.1 3.87 7.9 4.9 3.17
22 13.3 4.7 3.37 13.3 4.7 3.62 12.8 4.5 3.85 11.9 4.1 4.01 8.7 3.1 3.28
25
16 11.8 10.3 3.18 11.8 10.3 3.41 11.3 9.9 3.63 10.5 9.7 3.78 7.7 7.7 3.09
19 12.6 8.1 3.31 12.6 8.1 3.56 12.1 7.8 3.79 11.2 7.5 3.94 8.2 6.3 3.22
22 13.8 6.2 3.43 13.8 6.2 3.68 13.2 5.9 3.92 12.3 5.6 4.07 9.0 4.4 3.33
27
16 12.2 11.9 3.23 12.2 11.9 3.47 11.7 11.5 3.69 10.9 10.9 3.84 8.0 8.0 3.14
19 13.0 9.7 3.37 13.0 9.7 3.62 12.5 9.4 3.85 11.6 9.1 4.00 8.5 7.7 3.27
22 14.2 7.6 3.49 14.2 7.6 3.74 13.7 7.5 3.98 12.7 7.1 4.14 9.3 5.8 3.39
29
16 12.4 12.4 3.24 12.4 12.4 3.48 11.9 11.9 3.70 11.0 11.0 3.85 8.1 8.1 3.15
19 13.2 11.2 3.38 13.2 11.2 3.63 12.7 11.0 3.86 11.8 10.6 4.01 8.6 8.6 3.28
22 14.5 9.2 3.49 14.5 9.2 3.75 13.9 9.0 3.99 12.9 8.6 4.15 9.5 7.2 3.39
32
16 12.5 12.5 3.25 12.5 12.5 3.49 12.1 12.1 3.71 11.2 11.2 3.86 8.2 8.2 3.15
19 13.4 11.3 3.39 13.4 11.3 3.64 12.9 11.1 3.87 12.0 10.8 4.02 8.8 8.8 3.29
22 14.7 9.3 3.50 14.7 9.3 3.76 14.1 9.1 4.00 13.1 8.8 4.16 9.6 7.3 3.40
S-36PT2E5A×4
U-125PE1E5A
(U-125PE1E8A)
220V
230V
240V
50Hz
1phase
(3phase)
23
16 12.7 11.6 3.94 12.7 11.6 4.24 12.2 11.2 4.51 11.4 11.0 4.69 8.3 8.3 3.83
19 13.6 8.5 4.11 13.6 8.5 4.42 13.1 8.3 4.70 12.2 7.9 4.89 8.9 6.6 4.00
22 14.9 5.4 4.26 14.9 5.4 4.57 14.3 5.2 4.86 13.3 4.8 5.06 9.7 3.6 4.13
25
16 13.2 13.2 4.01 13.2 13.2 4.31 12.7 12.7 4.58 11.8 11.8 4.77 8.6 8.6 3.90
19 14.1 10.8 4.18 14.1 10.9 4.49 13.5 10.5 4.78 12.6 10.2 4.97 9.2 8.8 4.06
22 15.4 7.7 4.33 15.4 7.7 4.65 14.8 7.4 4.95 13.8 7.1 5.14 10.1 5.7 4.20
27
16 13.6 13.6 4.08 13.6 13.6 4.38 13.1 13.1 4.66 12.2 12.2 4.85 8.9 8.9 3.96
19 14.6 13.3 4.25 14.6 13.4 4.57 14.0 12.9 4.86 13.0 12.7 5.05 9.5 9.5 4.13
22 16.0 10.2 4.40 16.0 10.3 4.73 15.3 9.8 5.03 14.3 9.6 5.23 10.4 8.0 4.27
29
16 13.8 13.8 4.09 13.8 13.8 4.39 13.3 13.3 4.67 12.4 12.4 4.86 9.0 9.0 3.97
19 14.8 14.8 4.26 14.8 14.8 4.58 14.2 14.2 4.87 13.2 13.2 5.07 9.7 9.7 4.14
22 16.2 12.5 4.41 16.2 12.6 4.74 15.6 12.2 5.04 14.5 12.0 5.24 10.6 10.2 4.28
32
16 14.0 14.0 4.10 14.0 14.0 4.40 13.5 13.5 4.68 12.6 12.6 4.87 9.2 9.2 3.98
19 15.0 15.0 4.27 15.0 15.0 4.59 14.4 14.4 4.88 13.4 13.4 5.08 9.8 9.8 4.15
22 16.4 12.7 4.42 16.4 12.8 4.75 15.8 12.4 5.05 14.7 12.1 5.25 10.7 10.3 4.29
S-45PT2E5A×3
U-125PE1E5A
(U-125PE1E8A)
220V
230V
240V
50Hz
1phase
(3phase)
23
16 12.7 10.4 3.94 12.7 10.4 4.24 12.2 10.0 4.51 11.4 9.9 4.69 8.3 8.3 3.83
19 13.6 7.8 4.11 13.6 7.8 4.42 13.1 7.6 4.70 12.2 7.2 4.89 8.9 5.9 4.00
22 14.9 5.3 4.26 14.9 5.2 4.57 14.3 4.9 4.86 13.3 4.6 5.06 9.7 3.4 4.13
25
16 13.2 12.5 4.01 13.2 12.5 4.31 12.7 12.2 4.58 11.8 11.8 4.77 8.6 8.6 3.90
19 14.1 9.8 4.18 14.1 9.8 4.49 13.5 9.4 4.78 12.6 9.2 4.97 9.2 7.8 4.06
22 15.4 7.1 4.33 15.4 7.2 4.65 14.8 6.9 4.95 13.8 6.6 5.14 10.1 5.3 4.20
27
16 13.6 13.6 4.08 13.6 13.6 4.38 13.1 13.1 4.66 12.2 12.2 4.85 8.9 8.9 3.96
19 14.6 11.9 4.25 14.6 12.0 4.57 14.0 11.5 4.86 13.0 11.2 5.05 9.5 9.5 4.13
22 16.0 9.2 4.40 16.0 9.3 4.73 15.3 8.9 5.03 14.3 8.7 5.23 10.4 7.1 4.27
29
16 13.8 13.8 4.09 13.8 13.8 4.39 13.3 13.3 4.67 12.4 12.4 4.86 9.0 9.0 3.97
19 14.8 13.8 4.26 14.8 13.9 4.58 14.2 13.4 4.87 13.2 13.2 5.07 9.7 9.7 4.14
22 16.2 11.2 4.41 16.2 11.2 4.74 15.6 10.9 5.04 14.5 10.5 5.24 10.6 9.0 4.28
32
16 14.0 14.0 4.10 14.0 14.0 4.40 13.5 13.5 4.68 12.6 12.6 4.87 9.2 9.2 3.98
19 15.0 14.0 4.27 15.0 14.1 4.59 14.4 13.6 4.88 13.4 13.4 5.08 9.8 9.8 4.15
22 16.4 11.3 4.42 16.4 11.3 4.75 15.8 11.0 5.05 14.7 10.7 5.25 10.7 9.1 4.29
1-13. Capacity Table
1. Cooling Capacity Performance Data
•
Combination of Multiple Unit
Ceiling Type
TC :Cooling Capacity
SHC :Sensible Heat Capacity
IPT :Cooling Power Consumption
unit : kW
