Panasonic CZ-KPY3A series Service Manual

1
1-456
1-13. Capacity Table
2. Heating Capacity Performance Data
•
Combination of Multiple Unit
Ceiling Type
TC :Cooling Capacity
IPT :Cooling Power Consumption
unit : kW
Outdoor air intake temp(°C W.B.)
Model
Power
Source
Ambient
Return
Air
-5°C 0°C 6°C 10°C 15°C
DB TC IPT TC IPT TC IPT TC IPT TC IPT
S-36PT2E5A×2
U-71PEY1E5
220V
230V
240V
50Hz
1phase
16 5.6 1.95 6.1 2.04 8.3 2.38 9.4 2.59 10.6 2.80
20 5.5 2.05 6.0 2.14 8.1 2.51 9.1 2.73 10.2 2.95
24 5.2 2.11 5.7 2.21 7.8 2.59 8.7 2.81 9.8 3.03
S-50PT2E5A×2
U-100PEY1E5
(U-100PEY1E8)
220V
230V
240V
50Hz
1phase
(3 phase)
16 13.4 4.37 13.9 3.95 14.9 3.78 13.9 2.87 15.6 3.00
20 12.4 4.63 12.9 4.19 13.8 4.00 12.9 3.03 14.5 3.18
24 11.6 4.70 12.1 4.25 12.9 4.06 12.0 3.08 13.5 3.23
S-60PT2E5A×2
U-125PEY1E5
(U-125PEY1E8)
220V
230V
240V
50Hz
1phase
(3 phase)
16 14.5 4.81 15.2 4.35 16.2 4.16 15.1 3.15 17.0 3.30
20 13.5 5.09 14.0 4.60 15.0 4.40 14.0 3.34 15.7 3.50
24 12.6 5.17 13.1 4.68 14.0 4.47 13.1 3.39 14.7 3.55
S-71PT2E5A×2
U-140PEY1E8
220V
230V
240V
50Hz
3phase
16 16.7 5.53 17.2 5.44 17.3 4.92 17.3 4.34 17.3 3.67
20 15.5 5.85 15.9 5.75 16.0 5.21 16.0 4.59 16.0 3.88
24 14.5 5.94 14.9 5.85 15.0 5.29 15.0 4.66 15.0 3.94
