1-13. Capacity Table
2. Heating Capacity Performance Data
•
Combination of Single Unit
Wall Mounted Type
TC :Cooling Capacity
IPT :Cooling Power Consumption
unit : kW
Outdoor air intake temp(°C W.B.)
Model
Power
Source
Ambient
Return
Air
-5°C 0°C 6°C 10°C 15°C
DB TC IPT TC IPT TC IPT TC IPT TC IPT
S-60PK1E5A
U-60PEY1E5
220V
230V
240V
50Hz
1 phase
16 5.6 1.92 5.9 1.96 7.2 2.09 8.3 2.34 9.5 2.55
20 5.4 2.03 5.7 2.07 7.0 2.20 8.1 2.46 9.2 2.68
24 5.2 2.09 5.5 2.13 6.7 2.27 7.8 2.53 8.8 2.76
S-71PK1E5A
U-71PEY1E5
220V
230V
240V
50Hz
1 phase
16 5.6 1.98 6.1 2.07 8.3 2.42 9.4 2.63 10.6 2.84
20 5.5 2.08 6.0 2.18 8.1 2.55 9.1 2.77 10.2 2.99
24 5.2 2.14 5.7 2.24 7.8 2.63 8.7 2.85 9.8 3.08
S-100PK1E5A
U-100PEY1E5
(U-100PEY1E8)
220V
230V
240V
50Hz
1 phase
(3 phase)
16 10.2 3.28 10.6 2.97 11.3 2.83 10.6 2.15 11.9 2.25
20 9.4 3.47 9.8 3.14 10.5 3.00 9.8 2.28 11.0 2.38
24 8.8 3.53 9.2 3.19 9.8 3.05 9.2 2.31 10.3 2.42
