6-4
6
Display (functions)
ā¢ Use the temperature setting
and buttons to change the item code.
skrameRstnetnoc yalpsiDedoc metI
00(1) Outdoor unit contents (code) : OFF when normal
Blinking 8 - alarm code display at pre-trip,LED (2)
At initial status
01 No. of indoor units connected in that refrigerant system
02 Unit Nos. of connected indoor units in that refrigerant system *2
03 Operating status of indoor units in that refrigerant system (blinks when alarms occur)*2
04 Unit Nos. of indoor units in that refrigerant system where the thermostats are ON *2
detcennoc fo .oNmetsys tnaregirfer taht ni detcennoc stinu roo
dtuo fo .oN50
units :1
06 Unit Nos. of connected outdoor units in that refrigerant system *2
07 Operating status of outdoor units in that refrigerant system (blinks when alarms occur) *2
08
09
0A
0b
0C
0d
0E
0F
10 Total compressor operating time (in 1-h. units)*3
11
12
13
14
15
16 Total power ON time of outdoor unit (in 1-h. units)
17 Compressor start count
18
19
FE Outdoor unit microcomputer ļ¬ rmware version
FF Outdoor unit microcomputer software version
* See following page for *2 and *3.
ā¢ XX-YY R.C.
Displays the outdoor unit address of the selected outdoor sub-bus.
XX = Main bus line outdoor system address (1 ā 30)
YY = Outdoor unit address in outdoor sub-bus (1 ā 8). This is ā1ā
when there is only 1 outdoor unit.
LED
(3)
(1)
(2)
<Sample displays>
01: <No. of connected indoor units>
4 units connected
02: <Unit Nos. 1, 2, 3, and 4 are connected>
Locations where (1), (2), and (3) are
displayed as shown below.
