Panasonic DP-C405 - Page 141

141
FEB 2008Ver. 1.1
DP-C405/C305/C265
GLK(GND) Green LED Cathode Signal
GND Ground
GND_1 Ground
GND_2 Ground
GND_3 GND
GND_4 GND
GND_5 GND
GND_6 GND
GND_7 GND
GND_8 GND
GND_9 GND
GREENSCLK- Green AFE Serial Interface Shift Register Clock +
GREENSCLK+ Green AFE Serial Interface Shift Register Clock +
HSYNCC C Horizontal Synchronized Signal
HSYNCK K Horizontal Synchronized Signal
HSYNCM M Horizontal Synchronized Signal
HSYNCY Y Horizontal Synchronized Signal
HUMISN Humidity Sensor
IH_ROTSN2 Fuser Rotor Encoder Output 2
IHADIN IH AD Converter Data Output
IHADO IH AD Converter Data Input
IHPWR IH Power OWM Output
IO16 16 Bit Block Transfer Control Signal
IPRXD Finisher Serial RXD
IPTXD Finisher Serial TXD
KIN0 Key Input Signal
KIN3 Key Input Signal
KIN4 Key Input Signal
KIN5 Key Input Signal
KIN6 Key Input Signal
KYE No Connection
LD_ERS_C1 Discharge LED C Power Supply 1
LD_ERS_C2 Discharge LED C Power Supply 2
LD_ERS_K1 Discharge LED K Power Supply 1
LD_ERS_K2 Discharge LED K Power Supply 2
LD_ERS_M1 Discharge LED M Power Supply 1
LD_ERS_M2 Discharge LED M Power Supply 2
LD_ERS_Y1 Discharge LED Y Power Supply 1
LD_ERS_Y2 Discharge LED Y Power Supply 2
LDADUDR Right Sub Cover Sensor Power Supply
LDADUPP0 ADU Path Sensor 0 Power Supply
LDADUPP2 ADU Path Sensor 2 Power Supply
LDBL_C Bottle Motor Lock Detection Signal C Power Supply
LDBL_K Bottle Motor Lock Detection Signal K Power Supply
LDBL_M Bottle Motor Lock Detection Signal M Power Supply
LDBL_Y Bottle Motor Lock Detection Signal Y Power Supply
LDCST1a Tray 1 Sensor a Power Supply
Glossary of Electrical Abbreviations
Signal Name Function
