496
FEB 2008
Ver. 1.1
DP-C405/C305/C265
5.4. Control Panel Unit
Note:
This assembly does not include Ref. No. 1306, and 1330.
Safety
Mark
Ref.
No.
Part Number Part Name
New
Parts
Remarks Destination
1201 PJKZC0037Z
Assembly, Scanner Front
Cover
C All
1202 PJKPC0033Y Cover, PC Card N All
1203 PJKPC0034Z Plate, PC Card C All
1204 PJKPC0035Z Indicator C All
1205
PJGFC0606Z
Label, PC Card C
PU, PUG
PJGFC0606X Except PU, PUG
1206 PJBZC0002Z Cover, Back Panel C All
1207 PJUIC0228Z Bracket, Panel Guide C All
1208 PJBVC0112Z Spring, Damper C All
1209 PJUIC0227Z Bracket, Support C All
1210 PJBAC0036Z Bushing, Panel Guide C All
1211
PJGFC0467H
Label, Model Number N
For DP-C405
Except PK
PJGFC0467G For DP-C305
PJGFC0467F
For DP-C265
PJGFC0467K For DP-C405
PKPJGFC0467L For DP-C305
PJGFC0467M For DP-C265
1212 DZNM000006 Badge, Panasonic C All
1213 29K0 Latch C All
1214 CS-3U Coating Clip C PU, PUG, PT
1216 DZJL000286 Clip C All
1217 PJWPF331GPU
PC Board, SDI
(SD Card I/F)
N RTL/PbF All
1218 PJNAC0015Z Screw C All
1219 PJJEC3444Z Plate, PNL Ground C
Except PU, PUG,
PT
1224
PJZEF217TPU
Control Panel Unit C See Note
PU, PUG
PJZEF3160PB
Except PU, PUG,
PK, PT
PJZEF217PPK PK
PJZEF217PPT PT
1401 PJUEC0061Z Bracket, Scanner Base C All
1411 DZJK000061 Mini Clamp C All
1414 PJUIC0313Z Bracket, SCN-MCC C
Except PU, PUG,
PT
1415 PJHSC0063Z Gasket C
Except PU, PUG,
PT
X5 XTB3+6FFJ Screw C All
X9 XTB3+8FFJ Screw C All
Y47 XST3+4FJ Screw C All
To Next Page
