DP-C405/C305/C265
5.7. Upper Right Side Cover Unit
Safety
Mark
Ref. No.
Part Number Part Name
New
Parts
Remarks Destination
2101 PJUIC0161Y Bracket, Front Damper C All
2102 PJUIC0158Z Bracket, Front C All
2103 PJUGC0024Z Pin, Hinge C All
2104 PJUIC0160Z Bracket, Rear Damper C All
2105 PJHRC0052Z Bushing C All
2106 PJDEC0035Z Spacer C All
2107
PJUKC0119Z
Guide, Registration
N
For DP-C405/C305
All
PJUKC0029Z C
For DP-C265
All
2108 PJBAC0018Z Actuator, Registration C All
2109 PJBWC0018Z
Spring, Registration
Actuator
C
All
2110 PJWPF217HPU PC Board, ROHP C
PbF
All
2111 PJBUC0011Z Spring 2, Ground C
For DP-C265
All
2112 PJDRC0028Z Roller, Registration C All
2113 PJDGC0057Z Gear, D Z20M1 C All
2114 PJUIC0154Z Bracket, Lower Damper C All
2115 PJUSC0012Z Holder, Damper C All
2116 PJCGC0002Z Damper C All
2117 PJUIC0066Z Bracket, Ground C All
2118 PJULC0008Z Plate, Ground C All
2119 PJBVC0040Z Spring, Ground C All
2120 PJJRC2540Z Harness, DCG C All
2121 PJCGC0001Z Damper C All
2124 PJJRC2632Z Harness, E2 C
Except PU,
PUG, PT
2130 B3NZB0000011 Photo Sensor N
For DP-C405/C305
All
2131 PJUIC0338Z Plate, RI Sensor N
For DP-C405/C305
All
2132 PJUEC0250Z Plate, Registration N
For DP-C405/C305
All
2133 PJBUC0112Z Plate, GND Registration N
For DP-C405/C305
All
1329 DZJK000070 Locking Mini Clamp C
For DP-C405/C305
All
1410 LT-11 Edge Saddle C All
1828 FFPMQ0536 Bushing C All
1918-01 B3NZB0000006 Photo Sensor N
For DP-C405/C305
All
3328 PJBUC0087Y Plate 2, Spring C
For DP-C405/C305
All
6512 PJJRC2546Z Harness, ADU-RROHP C All
G6 FFPFJ0039B Snap Ring C All
F10 XTB3+8GFJ Screw C All
K6 XUC6VM E-Ring C All
X3 XYN3+F8FJ Screw C All
X5 XTB3+6FFJ Screw C All
Y27 XUC8VM E-ring C All
Y31 XYA3+FF8FJ Screw C All
