8.4. List of Connectors
Safety
Mark
Ref. No. Part Number Part Name Serial Number / Remarks
NPN List Of Connectors
J1001
PCB DC Controller
NPN Registration Motor (M2P)
J1002
PCB DC Controller
YA1033K376 Harness, Motor
J1003
PCB DC Controller
YA1033K375 Harness, Interface
J1004
PCB DC Controller
YA1033K374 Harness, Power Connecting
J1005
PCB DC Controller
YA1033K373 Harness, Dust Sensor
J1006
PCB DC Controller
YA1033K372 Harness, Sensor
J1007
PCB DC Controller
YA1033K371 Harness, Registration Sensor
J2002
NPN Punch Motor (M1P)
YA1033K376 Harness, Motor
J2003
SYS Saddle Finisher
YA1033K375 Harness, Interface
J2004
SYS Saddle Finisher
YA1033K374 Harness, Power Connecting
J2005
PCB Dust LED
YA1033K373 Harness, Dust Sensor
J2006
PCB Dust PTR
YA1033K373 Harness, Dust Sensor
J2007
NPN Slide Home Position Sensor (PI2)
YA1033K372 Harness, Sensor
J2008
NPN Punch Home Position Sensor (PI1)
YA1033K372 Harness, Sensor
J2009
NPN Clock Sensor (PI3)
YA1033K372 Harness, Sensor
J2010
PCB Registration PTR
YA1033K371 Harness, Registration Sensor
J2011
PCB Registration LED
YA1033K371 Harness, Registration Sensor
