Panasonic DP-C405 Service Handbook

712
FEB 2008
Ver. 1.1
DP-C405/C305/C265
7.11. Fold Assembly
Safety
Mark
Ref. No. Part Number Part Name
New
Parts
Remarks
16606 PF4139P253 Cam, Front Saddle
N
16608 PF4117K171 Fold Assembly
C
16611 4A1-7357-000 Pulley, 27T
C
16617 PF4139P375 Cam, Rear Saddle
N
16618 4A1-7364-000 Gear, 24T
C
16620 PF4139P205 Gear, 16T/42T
N
16621 PF4139P206 Gear, 21T
N
16622 PF4139P414 Roller, Fold
N
16625 4A1-7388-000 Spring, Tension
C
16630 4A1-7533-000 Hook, Spring
C
16632 4A1-7552-000 Bushing
C
16633 PF4113P439 Gear, SP-S
C
16634 PW060050 Polyslider
C
16636
ER050SU-D
E-Ring
C
16638 4A1-8330-000 Gear, 18T
C
16640 4A1-8332-000 Guide, Lower Paper Delivery
C
16642 PF4099K355 Clutch, Electromagnetic
C
(CL1, CN72)
16644 HP020100SCH Pin, Dowel
N
16646 PF4139P100 Pin, Dowel
N
16650 4A1-7476-000 Spring, Leaf
C
16672 4A1-7525-000 Roller
C
16681 4A1-7256-000 Roller
C
16682 4A1-7504-000 Harness Duct
C
16683 PF4139P610 Bracket, Top
N
16684 PF4139P108 Frame, Front
N
16685 PF4139P068 Frame, Rear
N
16686 4A1-7485-000 Bracket, Front Tension
C
16687 PF4139P127 Cam
N
5111 E314000729
IC, Photo-Interrupter
TLP1241
C
(PI11, PI12, CN40, CN41)
5509 XD3-2300-162 Pin, Dowel
C
7119 XD3-2200-102 Pin, Dowel
C
15704 FC2-2120-000 Screw, M4 x 7
C
15806 FC2-5827-000 Clip
C
15837 4A1-7566-000 Clip, Shaft
C
16006 FS2-1672-000 Bushing
C
16212 4A1-7573-000 Bushing
C
