684
FEB 2008
Ver. 1.1
DP-C405/C305/C265
7.2. Mounting Hardware
Safety
Mark
Ref. No. Part Number Part Name
New
Parts
Remarks
15701 PF4117P738 Panel, Front Mounting Kit
C
15702 PF4117P737 Panel, Mounting Kit
C
15703 4A1-8547-000 Adjuster
C
15704 FC2-2120-000 Screw, M4 x 7
C
15705 4A1-8537-000 Plate, Mounting Kit Stopper
C
15706 4A1-8538-000 Rail, Slide
C
15707 PF4117P739 Panel, Rear Mounting Kit
C
15708 4A1-8543-000 Duct, Access Mounting Kit
C
15709 PF4117P772 Panel, Middle Mounting Kit
C
15710 PF4117P699 Plate, Latch
C
15711 030060FWBP Screw
C
15712 PF4117K608 Bracket, Mounting Kit Slide
C
15713 4A1-8539-000 Bracket, Mounting Kit
C
15714 PF4117K002 Frame, Mounting Kit Front
C
15715 PF4117K003 Frame, Mounting Kit Rear
C
15716 4A1-8540-000 Bracket, Mounting Kit Sub
C
15717 PF4117P698 Bracket, Hook
C
15718 040080FWBI Screw
C
15719 PF4117K001
Frame, Foot C
15720 040300FNBP Screw, M4 x 30
C
5830 XB4-7401-007
Screw, M4 x 10 Truss Head
Tapping
C
To Next Page
