Panasonic DP-C405

700
FEB 2008
Ver. 1.1
DP-C405/C305/C265
7.7. Drive Assembly
Safety
Mark
Ref. No. Part Number Part Name
New
Parts
Remarks
16200 PF4117K910 Drive Assembly
C
16201 4A1-7301-000 Gear, 58T
C
16202 4A1-7302-000 Gear, 23T
C
16203 4A1-7303-000 Gear, 17T/65T
C
16204 4A1-7304-000 Gear, 15T/54T
C
16205 4A1-7305-000 Gear, 17T/29T
C
16206 4A1-7306-000 Gear, 20T
C
16207 4A1-7307-000 Pulley, 45T
C
16208 4A1-7338-000 Gear, 82T
C
16212 4A1-7573-000 Bushing
C
16214 FS2-1615-000 Bearing, Ball
C
16215 XF2-1807-000 Belt, Timing
C
16216 4A1-7300-000 Gear, 29T
C
16217 4S1-9081-000 Screw, M4 x 6
C
16218 4A1-7308-000 Flag, Clock Sensor
C
16219 PF4117P941 Motor, DC24V
C
(M7, CN71)
16220 E314000746 Photo-Interrupter
C
(PI14, CN52)
16221 4A1-7407-000 Spring, Compression
C
16222 PF4099K340 Harness, Stapler
C
(CN7, CN11, CN72)
16223 4S1-9049-000 Screw, M4 Stepped
C
16225 XD3-2300-182 Pin, Dowel
C
16226 4A1-7479-000 Plate, Drawer
C
16227 4A1-7516-000 Bracket, Drawer
C
16228 4A1-7229-000 Shaft, Gear 1
C
16229 4A1-7231-000 Shaft, Gear 2
C
16230 4F1-1563-000 Assembly, Gear Bracket
C
16231 4A1-7199-000 Plate, Motor Sensor
C
16232 4A1-7198-000 Bracket, Sub Gear
C
5829 XD3-2200-142 Pin, Dowel
C
15704 FC2-2120-000 Screw, M4 x 7
C
15837 4A1-7566-000 Clip, Shaft
C
15838 NS-CLP00010 Clip, Shaft
N
15922 4A1-7572-000 Bushing
C
16041 XD3-2200-122 Pin, Dowel
C
