5.11. Exit Unit
Safety
Mark
Ref. No.
Part Number Part Name
New
Parts
Remarks Destination
3201 PJUAC0119Z Bracket, Upper Plate C All
3202 PJUKC0037Z Guide, 2-Way ADU C All
3203 PJBAC0022Z Actuator, Upper C All
3204 PJBWC0020Z Spring, Upper Actuator C All
3205 PJUKC0036Z Guide, Switch C All
3206 PJUIC0102Z
Bracket, Front Switch
Guide
C
All
3207 PJUIC0105Z
Bracket, Rear Switch
Guide
C
All
3208 PJDRC0033Z Roller, Upper Pinch C All
3209 PJDJC0068Z Bushing C All
3210 PJUIC0112Z Base, Arm Switch C All
3211 PJBVC0050Z Spring, Solenoid C All
3212 L9AABEHC0001 Solenoid
C
All
3213 PJUAC0171Z Bracket, Solenoid C All
3214 PJBWC0030Z Spring, Solenoid2 C All
3215 PJBUC0059Z Plate 1, Spring C All
3216 PJUKC0049Z Guide, Harness C All
3217 PJUIC0108Z Bracket, Drive Plate C All
3218 PJDGC0065Z Gear, I Z22M1 C All
3219 PJDGC0066Z Gear, I Z18M1 C All
3220 PJUIC0104Z Bracket, Arm1 C All
3221 PJDGC0063Z Gear, I Z18M1 C All
3222 PJUGC0015Z Shaft, Idle Arm C All
3223 PJDGC0062Z Gear, I Z21M1Z28M1 C All
3224 PJDGC0064Z Gear, D Z27M1 C All
3225 PJDFC0071Z Shaft, Clutch C All
3226 PJUIC0110Z Bracket, Clutch C All
3227 PJBVC0048Z Spring, Arm C All
3228 PJSCC0004Z Brush, Upper C All
3229 PJBVC0047Z Spring, Pinch Roller 2 C All
3230 PJUSC0051Z Dampener, Rubber Noise C All
3231 PJUIC0263Y Plate, Ground C
Except PU, PUG,
PT
1819-38 B3NZA0000016 Photo Sensor N All
1946 DZLM000167 Bushing, D4 C All
2215 PJHRC0053Z Bracket, ADU Sensor C All
2305 DZLM000186 Bushing 2 C All
2731 L9EAAK000006 Clutch
C
All
6507 PJJRC2556Z Harness, ADU-ADTU0 C All
F10 XTB3+8GFJ Screw C All
H6 FFPFJ0033B Snap Ring C All
J6 XUC3VM E-Ring C All
J7 XUC4VM E-Ring C All
K5 XUC5VM E-Ring C All
X3 XYN3+F8FJ Screw C All
X5 XTB3+6FFJ Screw C All
Y16 XYN3+F6FJ Screw C All
