8.2. Puncher Assembly
Safety
Mark
Ref. No. Part Number Part Name Serial Number / Remarks
16900
YA1020K251
Puncher Assembly
DA-SP41-PU
YA1020K252 DA-SP41-PB
16901 YA1020K395C Puncher Controller PCB Assembly See Note
16902 YA1020P537 IC, CPU M38034M4-362SP See Note
16903 E323000483 IC, EP-ROM S-93C46ADP See Note
16904 4A1-8685-000 Shutter, Puncher
16905 YA1033K374 Harness, Power Connecting (J1004, J2004)
16906 YA1033K375 Harness, Interface (J1003, J2003)
16907 4A1-8683-000 Spring, Tension
16908 YA1033K372 Harness, Sensor (J1006, J2007-2009)
16910 4A1-8702-000 Label, Jam Removal
16911 YA1020P789 Mount, Puncher
16912 4A1-8673-000 Cover, Harness
16913 YA1020K367 Dust LED PCB Unit (J2005)
16914 YA1020K369 Dust PTR PCB Unit (J2006)
16915 4A1-8679-000 Gear, 16T/33T
16916 4A1-8680-000 Gear, 19T/32T
16917 4A1-8681-000 Duct, Puncher
16919 4A1-8686-000 Panel, Dust Box
16920 4A1-8687-000 Cover, Dust Box
16921 YA1020K303 Motor, Stepping (M2P, J1001)
16922 YA1033K373 Harness, Dust Sensor (J1005, J2005, J2006)
16923 4A1-8704-000 Cover, Puncher Base
16924 XB1-2400-605 Screw, M4 x 6 Truss Head Mach.
16925 XB4-7300-805 Screw, M3 x 8 Truss Head Tapping
16926 XD1-1104-629 Shim
16927 030060FZSW Screw, M3 x 6 w/Washer
16928 4F1-1850-000 Base
16929 4A1-8684-000 Bracket, Sensor
16930 4A1-8689-000 Filter
5111 E314000729 IC, Photo-Interrupter TLP1241 (PI2P, J2007)
15704 FC2-2120-000 Screw, M4 x 7
