DP-C405/C305/C265
nBCKE Clock Enable
nBCS2 Select for IC 1, 2
nBCS3 Select for IC 3, 4
nBCS4 Select for IC 5, 6
nBCS5 Select for IC 7, 8
nBDQMH Data Mask H Bite
nBDQML Data Mask L Bite
nBID0 Storage Capacity
nBID1 Storage Capacity
nBID2 Storage Capacity
nBLKCLP High-Active Black Level Clamp Switch Input Signal
nBMWT Memory Write
nBRAS RAW Address Select
nBTM_C Bottle Motor C Activation Signal
nBTM_K Bottle Motor K Activation Signal
nBTM_M Bottle Motor M Activation Signal
nBTM_Y Bottle Motor Y Activation Signal
nBWCT Monochrome Count
NC No Connection
nCBTMENB Belt Motor Enable
nCBTMRDY Belt Motor Lock Detection
nCCDRST CCD Board System Reset
nCCTCNT Card Counter Activation Signal
nCLPIN Input Clamp Enable
nCLPIN1 Input Clamp Enable
nCPPSN3 Tray 3 Paper Path Sensor Signal
nCPPSN4 Tray 4 Paper Path Sensor Signal
nCST3 Tray 3 Paper Feed Sensor Signal
nCST4 Tray 4 Paper Feed Sensor Signal
nCSTSN1a Tray 1 Detection Sensor
nCSTSN1b Tray 1 No Paper Sensor (Paper Tray Sensor : Tray 1 )
nCSTSN2a Tray 2 Detection Sensor
nCSTSN2b Tray 2 No Paper Sensor (Paper Tray Sensor : Tray 2 )
nCSTU3 Tray 3 Unit Sensor
nCSTU4 Tray 4 Unit Sensor
nDATA_C Image Data (C) +
nDATA_K Image Data (K) +
nDATA_M Image Data (M) +
nDATA_Y Image Data (Y) +
nDEV1ENB Developer Motor 1 Enable
nDEV1RDY Developer Motor 1 Lock Detection
nDEV2ENB Developer Motor 2 Enable
nDEV2RDY Developer Motor 2 Lock Detection
nDISPOFF Display Off Signal
nERSLED_C Discharge LED C Activation Signal
nERSLED_K Discharge LED K Activation Signal
nERSLED_M Discharge LED M Activation Signal
Glossary of Electrical Abbreviations
Signal Name Function
