Panasonic DP-C405

163
FEB 2008Ver. 1.1
DP-C405/C305/C265
CN501-69 NVDC1
SC PCB
CN61-25
C Data 1
CN501-70 NVDC2
SC PCB
CN61-26
C Data 2
CN501-71 NVDC3
SC PCB
CN61-27
C Data 3
CN501-72 NVDK0
SC PCB
CN61-28
K Data 0
CN501-73 NVDK1
SC PCB
CN61-29
K Data 1
CN501-74 NVDK2
SC PCB
CN61-30
K Data 2
CN501-75 NVDK3
SC PCB
CN61-31
K Data 3
CN501-76 DCLKY
SC PCB
CN61-32
Y Data Clock
CN501-77 DCLKM
SC PCB
CN61-33
M Data Clock
CN501-78 DCLKC
SC PCB
CN61-34
Data Clock C
CN501-79 DCLKK
SC PCB
CN61-35
K Data Clock
CN501-80 HSYNCY
SC PCB
CN61-36
Y Horizontal Synchronized
Signal
CN501-81 HSYNCM
SC PCB
CN61-37
M Horizontal Synchronized
Signal
EC PCB
Pin No.
Signal Name Destination Signal Waveform Function
+3.3V
0V
+3.3V
0V
+3.3V
0V
+3.3V
0V
+3.3V
0V
+3.3V
0V
+3.3V
0V
+3.3V
0V
+3.3V
0V
+3.3V
0V
+3.3V
0V
+3.3V
0V
+3.3V
0V
