Panasonic DP-C405

212
FEB 2008Ver. 1.1
DP-C405/C305/C265
EC PCB - CN528
EC PCB - CN529
EC PCB - CN530
EC PCB
Pin No.
Signal Name Destination Signal Waveform Function
CN528-1 +24VM
Lift Motor
(Tray2)
+24V DC Power Supply
CN528-2 nLUM2
Lift Motor
(Tray2)
Lift Up Motor 2
EC PCB
Pin No.
Signal Name Destination Signal Waveform Function
CN529-1
pFINISH_PO
W
LVS2 Finisher Power Supply
CN529-2 GND_1 LVS2 Ground
CN529-3 IPRXD Finisher Finisher Serial RXD
CN529-4 GND_2 Finisher Ground
CN529-5 IPTXD Finisher Finisher Serial TXD
CN529-6 GND_3 Finisher Ground
CN529-7 nFIN_SENS Finisher Finisher Sensor Signal
CN529-8
(DP-C405
Series Only)
GND_4 Finisher Ground
EC PCB
Pin No.
Signal Name Destination Signal Waveform Function
CN530-1 +24VF_1 Key Counter +24V DC Power Supply
+24V
0V
+24V
0V
+5V
0V
0V
+5V
0V
0V
+5V
0V
0V
+5V
0V
0V
+24V
0V
