Panasonic DP-C405

230
FEB 2008Ver. 1.1
DP-C405/C305/C265
ADF PCB - CN662 (DP-C405 Series Only)
CN661-5 PMB
Paper Feed
Motor-5
Paper Feed Motor B Signal
CN661-6 +24VO1
Paper Feed
Motor-3
+24 VDC Power Supply
CN661-7 PMBB
Paper Feed
Motor-1
Paper Feed Motor BB
Signal
CN661-8 MMA
ADF Main
Motor-11
ADF Main Motor A Signal
CN661-9 +24VO1
ADF Main
Motor-9
+24 VDC Power Supply
CN661-10 MMAB
ADF Main
Motor-7
ADF Main Motor AB Signal
CN661-11 MMB
ADF Main
Motor-5
ADF Main Motor B Signal
CN661-12 +24VO1
ADF Main
Motor-3
+24 VDC Power Supply
CN661-13 MMBB
ADF Main
Motor-1
ADF Main Motor BB Signal
CN661-14 N.C. No Connection
ADF PCB
Pin No.
Signal Name Destination Signal Waveform Function
CN662-1 GND
SCN
CN708-9
Ground
ADF PCB
Pin No.
Signal Name Destination Signal Waveform Function
+24V
0V
+24V
+24V
0V
+24V
0V
+24V
+24V
0V
+24V
0V
+24V
+24V
0V
0V
