Panasonic DP-C405 Service Handbook

478
FEB 2008
Ver. 1.1
DP-C405/C305/C265
Inverting Automatic Document Feeder
Safety
Mark
Ref. No.
Part Number Part Name
New
Parts
Remarks Destination
501 DZJA000921 Bracket, Rear ADF Cover C All
502 PJKCC0017Z Cover, ADF N All
505 PJZVF2750PU
Assembly, Paper Feed
Roller Shaft
C All
506 DZJM001414 Arm 1, Connection C All
507 DZJA001572 Bracket, Pickup C All
508 PJDRC0137Z Roller, Paper Feed N PM All
509 DZLF000468 Gear, Paper Feed Idle C All
510 DZKG000210 Shaft, Pickup Roller C All
511 PJDRC0091Z Roller, Pickup C PM
All
513 PJBAC0046Z Stopper, Original N All
514 DZJA000883 Bracket, Original Stopper C All
515 DZJM000716 Stopper, Arm C All
516 DZKN000346 Spring, Stopper Arm C All
517 DZJM000711 Bracket 2, Pickup C All
518 DZJA001574 Bracket, Latch Shaft C All
519 DZJA000938 Bracket, Front ADF Cover C All
521 PJDBC0109Z Actuator, Original Sensor N All
522 DZJM000718
Actuator, Registration
Sensor
C All
523 PJUEC0249Z Bracket 1, Original Sensor N All
524 DZKG000214 Shaft 1, Pinch Roller C All
525 PJUKC0122Z
Guide, Upper Opening And
Shutting
N All
526 DZJM000761 Sheet 1, Vibration Guide C All
527 DZJM000767 Sheet 2, Vibration Guide C All
528 DZJM000724 Guide, Vibration C All
529 DZJA000937
Bracket, Opening And
Shutting Front
C All
530 DZJA001573
Bracket 2, Original
Stopper
C All
531 DZKN000349 Spring 2, Ground C All
532 DZLF000492 Gear, 24T C All
533 PJDEC0062Z Torque Limiter C All
534 DZKQ000078
Spring, Registration
Sensor
C All
535 DZKP000319
Plate Spring 2, Pinch
Roller
C All
537 PJZVF3311AZ Paper Feed Unit N All
538 PJBVC0145Z Spring, Pick Up C All
540 PJDJC0076Y Bushing, Metal C All
542 PJNAC0018Z Shoulder screw C All
543 PJDIC0021Z Joint C All
401-05
B3NZA0000019 Photo Sensor 1 N All
401-06
705 DZJM000722 Holder, Sensor C All
