Panasonic DP-C405 Service Handbook

522
FEB 2008
Ver. 1.1
DP-C405/C305/C265
Safety
Mark
Ref. No.
Part Number Part Name
New
Parts
Remarks Destination
2201 PJKCC0004Y Cover, ADU C All
2202 DZJE001259 Knob, Cover 1 C All
2203 PJUIC0137Z Plate, Cover C All
2204 PJKPC0010Z Cover, Harness C All
2205 PJGTC0022Z Label, Caution C All
2206 PJKPC0022Z Cover 2, Harness C All
2207 PJUKC0042Z Guide, ADU Upper C All
2208 PJBXC0010Z Spring, Ground C All
2209 PJUGC0021Z Shaft, Latch Lever C All
2210 PJBAC0024Z Latch C All
2211 PJBWC0024Z Spring, Left Latch C All
2212 PJBWC0023Z Spring, Right Latch C All
2213 PJDJC0069Z Bushing C All
2214 L6FAKEDK0007 Fan, Right Cover C All
2215 PJHRC0053Z Bracket, ADU Sensor C All
2216 PJBAC0025Z Actuator, ADU Upper C All
2217 PJBVC0061Z
Spring, ADU Upper
Actuator
CAll
2218 KU-5 Clipple C All
2219 CS-9U Clip, Coating C All
1411 DZJK000061 Mini Clamp C All
1819-31 B3NZA0000016 Photo Sensor N All
6509 PJJRC2554Z Harness, ADU-ADTU1 C All
F10 XTB3+8GFJ Screw C All
J7 XUC4VM E-Ring C All
K5 XUC5VM E-Ring C All
X3 XYN3+F8FJ Screw C All
X4 XTB3+20GFJ Screw C All
