Panasonic DP-C405

692
FEB 2008
Ver. 1.1
DP-C405/C305/C265
Safety
Mark
Ref. No. Part Number Part Name
New
Parts
Remarks
15960 4A1-7174-000 Bracket, Stopper C
15961 4F1-1883-000 Bracket, Front Tray C
15962 4F1-1882-000 Bracket, Rear Tray C
15963 4A1-7510-000 Duct, MR C
15964 4F1-1558-000 Bracket, Front Tension C
15965 4F1-1560-000 Bracket, Rear Tension C
15966 4A1-7474-000 Bracket, Front C
15967 4A1-7543-000 Duct, IN C
15968 4A1-7489-000 Bracket, Reinforcement C
15969 4A1-7491-000 Bracket, Frame C
15970 PF4109P427 Screw, M4 C
5111 E314000729
IC, Photo-Interrupter
TLP1241
C (PI24, CN73)
5609 XF2-1605-040 Belt, Timing C
5829 XD3-2200-142 Pin, Dowel C
5830 XB4-7401-007
Screw, M4 x 10 Truss Head
Tapping
C
15704 FC2-2120-000 Screw, M4 x 7 C
15806 FC2-5827-000 Clip C
15835 4A1-7400-000 Spring, Tension C
15838 NS-CLP00010 Clip, Shaft N
16018 NS-BLT00230 Belt, Timing C
