Panasonic DP-C405

706
FEB 2008
Ver. 1.1
DP-C405/C305/C265
Safety
Mark
Ref. No. Part Number Part Name
New
Parts
Remarks
16459 PF4114P403 Sheet, M
C
16460 PF4114P407 Sheet, R
C
5111 E314000729
IC, Photo-Interrupter
TLP1241
C
(PI2, PI6-I8, PI15, CN30-
32, CN50, CN51)
5830 XB4-7401-007
Screw, M4 x 10 Truss Head
Tapping
C
7119 XD3-2200-102 Pin, Dowel
C
15704 FC2-2120-000 Screw, M4 x 7
C
15806 FC2-5827-000 Clip
C
15838 NS-CLP00010 Clip, Shaft
N
15922 4A1-7572-000 Bushing
C
15936 FC2-5034-000 Screw, M3 x 6 w/Washer
C
16006 FS2-1672-000 Bushing
C
16013 PF4117K323 Harness, Sensor
C
(CN54, CN55)
16017 4H1-6449-000 Microswitch
C
(MS3, CN66)
16041 XD3-2200-122 Pin, Dowel
C
16050 PF4060P027 Screw, M4 x 8
C
