710
FEB 2008
Ver. 1.1
DP-C405/C305/C265
Note:
This assembly is included in the assembly shown in Figure F-09.
Safety
Mark
Ref. No. Part Number Part Name
New
Parts
Remarks
16562 PF4113P419 Sheet, Rear ML
C
16563 PF4113P413 Sheet, Front ML-SR
C
16564 PF4113P414 Sheet, Rear ML-SR
C
16565 PF4117P271 Sheet, SR-MLR-GID L
C
16566 PF4117P270 Sheet, SR-MLR-GID
C
16567 4B1-0149-000 Holder, SIRC-SR Paddle
C
16568 4B1-0111-000 Holder, KM-SR Paddle
C
16569 4B1-0140-000 Paddle 1, KM-SR
C
16570 4B1-0148-000 Paddle, THIN
C
16571 PF4136K117 Assembly, Paper Exit Roller
C
16572 PF4110P957 Guide, Exit Roller
C
5111 E314000729
IC, Photo-Interrupter
TLP1241
C
(PI3, PI5, CN36, CN55)
5830 XB4-7401-007
Screw, M4 x 10 Truss Head
Tapping
C
7119 XD3-2200-102 Pin, Dowel
C
15704 FC2-2120-000 Screw, M4 x 7
C
15806 FC2-5827-000 Clip
C
15808 4A1-7380-000 Spring, Tension
C
16006 FS2-1672-000 Bushing
C
16404 XF2-1606-140 Belt, Timing
C
To Next Page
