Panasonic DP-C405

722
FEB 2008
Ver. 1.1
DP-C405/C305/C265
Safety
Mark
Ref. No. Part Number Part Name
New
Parts
Remarks
16704 4A1-8215-000 Frame, Coupling
C
16706 4A1-8218-000 Coupling
C
16707 4A1-8219-000 Spring, Compression
C
16708 4A1-7591-000 Holder, Staple Guide Roller
C
16709 4A1-7589-000 Roller, Staple Guide
C
16712 4A1-8226-000 Gear, 38T 36T/Pulley
C
16714 4A1-8229-000 Gear, 32T 42T/Pulley
C
16715 4A1-8230-000 Pulley, 24T
C
16716 XF2-1809-000 Belt, Timing
C
16720 FC2-5035-000 Screw, M3 x 6 w/Washer
C
16724 4A1-8265-000 Cover, Right Side
C
16725 4A1-8264-000 Cover, Left Side
C
16730 4A1-8263-000 Cover, Gear
C
16734 4A1-8341-000 Staple Cartridge Unit
C
16737 PF4117K312 Stapler Base PCB Assembly
C
16738 PF4117K313 Stapler In PCB Assembly
C
16739 PF4117P530 Harness, Stapler
C
(JN1, JN2)
16740 PF4117K314 Harness 1, Staple
C
(JN2)
16760 XD3-2300-122 Pin, Dowel
C
16764 NS-BLT00234 Belt
C
16765 XF2-1309-711 Belt
C
5413 XD2-1100-502 E-Ring
C
5511 XD2-1100-642 E-Ring
C
5829 XD3-2200-142 Pin, Dowel
C
