U. Plain Washers, Spring Washers & Toothed Lock Washers
How to Read Part NumbersPlain Washers
d
XD1–2 1 0 0 –307
Plain washer
Inner diameter (d) ......... 3.0mm
Material and surface
treatment .......................Steel (nickel plated)
How to Read Part NumbersSpring Washers
How to Read Part NumbersToothed Lock Washers
d
XD1–3 1 0 0 –507
Spring washer
Inner diameter (d) ......... 5.0mm
Material and surface
treatment .......................Steel (nickel plated)
d d
Outer toothed
type
Inner toothed
type
XD1–4 1 0 0 –302
XD1 – 410
Toothed lock washer
Inner diameter (d) ......... 3mm
....... Inner toothed type
XD1 – 420 ....... Outer toothed type
Material and surface
treatment .......................Stainless
(without surface treatment)
