Y. Spring and Dowel Pins
How to Read Part Numbers
How to Read Part Numbers
V. Pins
Spring Pins
Dowel Pins
d
XD3–1 2 0 0 –122
Nominal diameter (D) .......................
Spring pin
Material and surface treatment ........
Length ( ) ........................................
2.0 mm
12 mm
Stainless
(without surface treatment)
Z. Spacer
How to Read Part Numbers
VI. Spacers
d
XD3–2 2 0 0 –082
Nominal diameter (d) .......................
Dowel pin
Material and surface treatment ........
Length ( ) ........................................
2.0 mm
8 mm
Stainless
(without surface treatment)
d
XZ1–1 3 0 0 –305
Nominal diameter (d) .......................
Spacer
Material and surface treatment ........
Length ( ) ........................................
3.0 mm
3.0 mm
Steel
(zinc plated)
