2.2 Wiring the LAN Port
2.2 Wiring the LAN Port
Selection of UTP cables
• Use Category 5 UTP cable.
• It is recommended to use a UTP cable of 10 m or shorter, taking account of noise resistance.
• In an environment where noise may occur, attach a ferrite core near the CPU unit on the
UTP cable. It is also recommended to use a shielded cable.
• For installation of 100BASE-TX or 10BASE-T hub, laying of cables, etc.,
please consult a specialized construction company. If this construction
work is done incorrectly, it can adversely affect the entire network, and can
cause accidents.
