3.2 Setting Basic Communication Information
3.2 Setting Basic Communication Information
3.2.1 List of Setting Items
 List of setting items (basic communication information)
Setting item Default Remark
Automatic getting of
IPv4 address
No
Own IP address (IPv4) 192.168.1.5
Subnet mask (IPv4) 255.255.255.0
Default gateway
(IPv4)
192.168.1.1
This is valid as long as the network (subnetwork) mask field is
anything other than 0.
If the default router (gateway) IP address has been set,
communication will be carried out through the default router
(gateway) without an error occurring even f the class, network
address, or subnetwork address of the partner node differ from
those of the source node.
The network (subnetwork) address for the default router
(gateway) IP address must be identical to the network
(subnetwork) address for the source node IP address. If they are
different, an error will occur.
・0000 0000 H and FFFF FFFF H is regarded as an error.
TCP ULP time-out value 5
Setting range: 0001 - FFFF: (by 100 ms)
With TCP, this specifies the time that a packet exists when data
transmission, etc. is carried out. "TCP ULP" should be specified
at an integral multiplication of "TCP re-transmission timer value".
When an integral multiplication cannot be given, round up the
given decimal number.
TCP zero-window
timer value
5
Setting range: 0001 - FFFF: (by 100 ms)
With TCP, this specifies the time until the receive window size
check packet is re-sent when the receive window size of the
other node becomes 0.
TCP re-transmission
timer value
5
Setting range: 0001 - FFFF: (by 100 ms)
With TCP, this specifies the time until data is re-sent if ACK is
not sent by the other node, when data transmission, etc. is
carried out.
TCP closed timer value 20
Setting range: 0001 - FFFF: (by 100 ms)
This specifies the time waited until open processing is carried
out when the same port is being re-opened, when TCP close
processing is done by the source node.
IP assembling timer
value
3
Setting range: 0001 - FFFF: (by 100 ms)
This specifies the time waited for the next portion of data when
data split by the IP is being received.
TCP terminal detection
timer value
20
Setting range: 0001 - FFFF: (by 1 ms)
When divided TCP segments are received, specify the time for
monitoring the arrival of the following segment.
TCP reception is regarded as completed if no data are received
after the time as specified above has passed.
IP address of the DNS
server
Set manually
Prioritized DNS server 0.0.0.0
Substitute DNS server 0.0.0.0
3-3
