7.3 Receiving Operation
7.3.3 GPRECV (General-Purpose Communication Receiving Command)
 Command format
Setting
item
Settings Setting range
i Specify the operation unit. US / SS
D1 Specify the initial address of the data area to save the received data. (Note 1)
D2 Specify the final address of the data area to save the received data. (Note 2)
(Note 1): Devices that can be specified for D1 are: WX, WY, WR, WL, DT, LD.
(Note 2): Devices that can be specified for D2 are: WX, WY, WR, WL, DT, LD.
KEY POINTS
• Specify the connection targeted for communication, using UNITSEL
command immediately before GPRECV command.
• When the general-purpose communication reception done flag is ON for the
targeted connection, execute GPRECV.
7-11
