3.5 Setting of System Connection
3.5 Setting of System Connection
3.5.1 List of Setting Items
System connection is used when using a programming tool via LAN port.
 List of setting items
Setting item
Default
System Connection - Setting method
Operation Mode Setting MEWTOCOL-COM Select the operation mode MEWTOCOL-COM.
Setting of application use
Specifying use of
connection
Yes Specify whether system connection is to be used.
MEWTOCOL
communication type
Do not connect with FP2
ET-LAN
Select "Do not connect with FP2 ET-LAN".
Open method
(server/client)
Server connection
(unspecified partner)
Select connection function settings (server
connection (unspecified partner).
Open method
(auto/manual)
Auto OPEN
Select the connection open method (auto/manual).
Select "Auto OPEN".
Communication method TCP / IP Select the communication protocol (TCP/IP).
Source node port No.
Connection 01: 32769
Connection 02: 32770
Connection 03: 32771
Connection 04: 32772
Specify the source node (sender) port number.
Partner node port No.
Connection 01: 32769
Connection 02: 32770
Connection 03: 32771
Connection 04: 32772
Specify the partner node (receiver) port number.
This needs not to be set if the partner node is not
specified.
Connection closing time
Connection 01: 6000
Connection 02: 360000
Connection 03: 360000
Connection 04: 360000
Setting unit:
Input the no-connection communication monitoring
time. Connection is automatically cut off when no-
connection communication exceeds the specified
time.
Partner node - Setting
method
Specification using IP
address (IPv4)
Select the setting for partner node (IP address).
This needs not to be set if the partner node is not
specified.
Partner node IP address and
name
0.0.0.0
Specify the setting for partner node (IP address /
host name). This needs not to be set if the partner
node is not specified.
3-7
