FP Positioning Unit Specifications
16-3
16.1 Table of Performance Specification
General specifications
Item Description
Ambient operating
temperature
0 to +55 °C/32F to +131F
Ambient storage
temperature
-20 to +70 °C/ - 4F to +158F
Ambient operating
humidity
30 to 85 % RH (at25°C non-condensing)
Ambient storage
humidity
30 to 85 % RH (at25°C non-condensing)
Breakdown voltage
500 V AC, 1 minute
Between the various pins of the external connector and the
ground
Insulation resistance
100M or more (measured with 500 V DC testing)
Between the various pins of the external connector and the
ground
Vibration resistance
10 to 55 Hz, 1 cycle/min. (double amplitude of 0.75 mm/0.030 in., 10 min. each in
the X, Y, Z directions)
Shock resistance Shock of 98 m/s
2
, 4 times in the X, Y, Z directions
Noise immunity 1,000 V[P-P] with pulse widths 50ns and 1µs (based on in-house measurements)
Operating environment Free of corrosive gases and excessive dust
