Panasonic FPG Series User Manual

FP∑ Positioning Unit Wiring
3-15
3.8 Precausions on Wiring
Connect the wire in less than or the following length between the Transistor output type and the motor
driver, and between the Line driver output type and the motor driver.
<Signals applicable>
Transistor output
Line driver output
Deviation counter clear output
Output type Product number Wiring length
AFPG 430
Transistor output type
AFPG 431
AFPG 432
Line driver output type
AFPG 433
10m

Panasonic FPG Series Specifications

General

High-speed counter	Up to 100 kHz
Input Voltage	24 V DC
Dimensions	Varies by model
Weight	Varies by model
Program Capacity	32 k steps
Programming Language	Ladder Logic
Communication	RS232C, RS485, Ethernet
Pulse output	100 kHz
Operating Temperature	0 to 55 °C
Supply Voltage	24V DC or 100-240V AC
Output Type	Relay, Transistor
Storage Temperature	-20 to 70 °C
Humidity	5 to 95% RH (non-condensing)
