OPERATING INSTRUCTIONS
MCUK990801C8 Section 3 Issue 1
Service Manual – 7 – Revision 0
3.4 Concept of Operation
There is a close relationship between the Select Key, Navigation Key and display.
Figure 3.3: Concept of Operation
Pressing up and down (
e) will move the pointer up and down and scroll through more information in the main area of the
display.
Pressing left and right (f) will scroll through options in the option area of the display. To choose the option press the Select
Key (
B).
3.5 Alpha Entry
Alpha Entry is used to enter alphanumeric characters into Phonebook, Short Messages and the Greeting Message.
Each time a key is pressed it will display the next character. When another key is pressed or no key is pressed for a short time
the cursor will move to the next position.
To cycle between Greek characters (V), extended characters (W), numerals (X) and normal characters (U) press A.
3.5.1 Editing Alpha Entry
Pressing e will move the cursor up or down one line. Pressing f will move you left or right one character. When the cursor
is moved over a character and another key pressed this will insert the new character.
Pressing C will delete the character to the left of the cursor.
3.6 Incoming Calling Line Identification (CLI)
When a call is received the last 6 digits of the CLI information is matched with the phonebook. Therefore an incoming call could
match to the wrong phonebook entry.
Key Character/Operation
UVWX
1
“ @ – , . ; : ! ¡ ? ¿ ( ) ‘ & % + – / < > = £ $ ¥ ¤ § 1
2 A B C a b c ⊥ _ δ A Ä Å Æ B C Ç a à b c 2
3 D E F d e f α β=ω D E É F d e è é f 3
4 G H I g h i ε ν φ G H I g h i ì 4
5 J K L j k l η ι ϕ J K L j k l 5
6 M N O m n o κ υ λ M N Ñ O Ö ø m n ñ o ò ö 6
7 P Q R S p q r s µ=ο π P Q R S p q r s ß 7
8 T U V t u v θ ρ χ T U Ü V t u ù ü v 8
9 W X Y Z w x y z υ=ϖ=τ W X Y Z w x y z 9
C Deletes the character above the cursor, deletes the character to the left when at the end of the line or clears the entire entry
when pressed and held.
11025-1
